| Nomor Bagian | AM-640480G2TNQW-A0H |
| Merek | AMPIRE |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 640×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 250:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | AMPIRE |
| model | AM-640480G2TNQW-A0H |
| ukuran diagonal | 5.7 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 640(RGB)×480 [VGA] 141PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 115.2(H)×86.4(V) mm |
| garis besar redup. | 127(H)×98.43(V) ×7.8(D) mm |
| daerah bezel | 118.0(H)×89.2(V) mm |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 500 cd/m² (Typ.) |
| rasio kontras | 250:1 (Typ.) (TM) |
| arah pandangan | 12 o'clock |
| waktu merespon | 50 (Typ.)(Tr+Td) |
| sudut pandang | 70/70/50/50 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 262K 50% NTSC |
| sumber cahaya | WLED , 20K hours , With LED Driver |
| berat | - |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 6-bit) , 20 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
