| Nomor Bagian | AM-240320GTZQW-02H |
| Merek | AMPIRE |
| Ukuran | 2.8 |
| Aplikasi | Mobile Phone |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 450:1 |
| Warna | 65K |
| Lampu latar | WLED |
| Antarmuka | CPU/RGB/SPI |
| merek | AMPIRE |
| model | AM-240320GTZQW-02H |
| ukuran diagonal | 2.8 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 240(RGB)×320 [QVGA] 141PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 43.2(H)×57.6(V) mm |
| garis besar redup. | 49(H)×67.5(V) ×4.9(D) mm |
| pencahayaan | 280 cd/m² (Typ.) |
| rasio kontras | 450:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 15/20 (Typ.)(Tr/Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| Modus operasi | MVA, Normally Black, Transmissive |
| warna pendukung | 65K 69% NTSC |
| sumber cahaya | WLED [3S2P] , With LED Driver |
| berat | TBD |
| dirancang untuk | Mobile Phone |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | CPU/RGB/SPI , 40 pins FPC |
| Sumber Daya listrik | 2.8V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
