| Nomor Bagian | AM-19201200FTZQW-T05 |
| Merek | AMPIRE |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1920×1200 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | AMPIRE |
| ukuran panel | 10.1" |
| resolusi | 1920(RGB)×1200, WUXGA, 224PPI |
| area tampilan | 216.806(W)×135.504(H) mm |
| ukuran garis besar | 227.72(W)×146.13(H) ×7.2(D) mm |
| kecerahan | 320 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 50% NTSC |
| frekuensi | 60Hz |
| berat panel | - |
| antarmuka sinyal | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | AM-19201200FTZQW-T05 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | - |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | AHVA, Normally Black, Transmissive |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| jenis lampu | WLED , 30K hours , With LED Driver |
| layar sentuh | PCAP |
| aplikasi | Industrial |
