| Nomor Bagian | AM-19201200CTZQW-T01 |
| Merek | AMPIRE |
| Ukuran | 10.1 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1920×1200 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek | AMPIRE |
| model | AM-19201200CTZQW-T01 |
| ukuran diagonal | 10.1 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1920(RGB)×1200 [WUXGA] 225PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 216.576(H)×135.36(V) mm |
| garis besar redup. | 244.8(H)×155.3(V) ×8.01(D) mm |
| pencahayaan | 850 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | AHVA, Normally Black, Transmissive |
| warna pendukung | 16.7M 49% NTSC |
| sumber cahaya | WLED [7S6P] , 50K hours , W/O Driver |
| berat | - |
| dirancang untuk | Industrial Outdoor High Brightness |
| kecepatan bingkai | 60Hz |
| panel sentuh | PCAP |
| Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
