| Nomor Bagian | AM-19201200CTZQW-00 |
| Merek | AMPIRE |
| Ukuran | 10.1 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1920×1200 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| pabrikan | AMPIRE |
| nama model | AM-19201200CTZQW-00 |
| ukuran layar | 10.1 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1920(RGB)×1200 (WUXGA) 225PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 216.576 × 135.36 (H×V) |
| garis besar (mm) | 244.8 × 155.3 × 7 (H×V×D) |
| pencahayaan | 1000 cd/m² (Typ.) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 25 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | AHVA, Normally Black, Transmissive |
| kedalaman warna | 16.7M 49% NTSC |
| lampu latar | WLED , 50K hours , With LED Driver |
| massa | - |
| digunakan untuk | Industrial Outdoor High Brightness |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -20 ~ 65 °C Operating Temp.: -20 ~ 65 °C |
