| Nomor Bagian | AM-1024600K5TMQW-T00H |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial |
| Resolusi | 1024×600 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | 5S3P |
| Antarmuka | LVDS |
| pabrikan | AMPIRE |
| nama model | AM-1024600K5TMQW-T00H |
| ukuran layar | 7.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1024(RGB)×600 (WSVGA) 169PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 153.6 × 90 (H×V) |
| garis besar (mm) | 165.5 × 103 × 11.02 (H×V×D) |
| pencahayaan | 400 cd/m² (Typ.) |
| rasio kontras | 700 : 1 (Typ.) (TM) |
| sudut pandang | 75/75/70/75 (Typ.)(CR≥10) |
| tanggapan | 20/20 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | - |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 16.7M |
| lampu latar | 5S3P WLED , 30K hours , With LED Driver |
| massa | TBD |
| digunakan untuk | Industrial |
| tingkat penyegaran | 60Hz |
| layar sentuh | 4-wire Resistive Touch |
| jenis sinyal | LVDS (1 ch, 8-bit) , Connector 20 pins |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
