| Nomor Bagian | AM-1024600ITZQW-T00H |
| Merek | AMPIRE |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1024×600 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | AMPIRE |
| ukuran layar | 10.1 inch |
| nomor piksel | 1024(RGB)×600 (WSVGA) 117PPI |
| area aktif (mm) | 222.72 × 125.28 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 465 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 262K/16.7M 70% NTSC |
| massa | - |
| tingkat penyegaran | 60Hz |
| jenis sinyal | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| sumber tegangan | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| nama model | AM-1024600ITZQW-T00H |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 255 × 165.8 (H×V×D) |
| perlakuan | Antiglare, Hard coating |
| rasio kontras | 500 : 1 (Typ.) (TM) |
| tanggapan | 12/28 (Typ.)(Tr/Td) ms |
| mode kerja | IPS, Normally Black, Transmissive |
| lampu latar | WLED , 50K hours , No Driver |
| digunakan untuk | Industrial |
| layar sentuh | PCAP |
