| Nomor Bagian | AM-1024600ITZQW-00H |
| Merek | AMPIRE |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | AMPIRE |
| model panel | AM-1024600ITZQW-00H |
| ukuran panel | 10.1" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1024(RGB)×600, WSVGA, 117PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 222.72(W)×125.28(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 234.9(W)×143(H) ×4.9(D) mm |
| permukaan | Antiglare, Hard coating |
| kecerahan | 550 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| mode tampilan | IPS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 12/28 (Typ.)(Tr/Td) |
| menampilkan warna | 262K/16.7M 70% NTSC |
| jenis lampu | WLED , 50K hours , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | - |
| aplikasi | Industrial |
| antarmuka sinyal | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| tegangan masukan | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
