| Nomor Bagian | AM-1024600DTZQW-TA6H |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | AMPIRE |
| model | AM-1024600DTZQW-TA6H |
| ukuran diagonal | 7.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×600 [WSVGA] 170PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 154.221(H)×85.92(V) mm |
| garis besar redup. | 164.9(H)×128(V) ×12.6(D) mm |
| pencahayaan | 850 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 13/15 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M 58% NTSC |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| berat | - |
| dirancang untuk | Industrial Outdoor High Brightness |
| kecepatan bingkai | 60Hz |
| panel sentuh | PCAP |
| tipe antarmuka | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
