| Nomor Bagian | AM-1024600DTZQW-TA0H |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | AMPIRE |
| ukuran panel | 7.0" |
| resolusi | 1024(RGB)×600, WSVGA, 170PPI |
| area tampilan | 154.221(W)×85.92(H) mm |
| ukuran garis besar | 184(W)×128(H) ×12.6(D) mm |
| kecerahan | 425 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 58% NTSC |
| frekuensi | 60Hz |
| berat | - |
| model panel | AM-1024600DTZQW-TA0H |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | - |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | IPS, Normally Black, Transmissive |
| waktu merespon | 13/15 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 30K hours , With LED Driver |
| layar sentuh | PCAP |
| aplikasi | Industrial |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA070MA32BW | CPT | 7.0 | 800×600 |
| EDTCB18QEF | TOSHIBA | 7.0 | 800×480 |
| LB070WV1-TD17 | LG Display | 7.0 | 800×480 |
| PM070WX1 | E Ink | 7.0 | 800×480 |
| TR-LM7WR3PS | Panasonic | 7.0 | 480×234 |
