| Nomor Bagian | AM-1024600DTZQW-A6H |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1024×600 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | AMPIRE |
| nama model | AM-1024600DTZQW-A6H |
| ukuran layar | 7.0 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 1024(RGB)×600 (WSVGA) 170PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 154.221 × 85.92 (H×V) |
| garis besar (mm) | 164.9 × 100 (H×V×D) |
| area bezel (mm) | 158 × 89.7 (H×V) |
| perlakuan | Antiglare |
| pencahayaan | 1000 cd/m² (Typ.) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 13/15 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M |
| lampu latar | WLED , 50K hours , With LED Driver |
| massa | - |
| digunakan untuk | Industrial Outdoor High Brightness |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | LVDS (1 ch, 8-bit) , 20 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
