| Nomor Bagian | AA106TA01DDE11 |
| Merek | Mitsubishi |
| Ukuran | 10.6 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1280×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek | Mitsubishi |
| model | AA106TA01DDE11 |
| ukuran diagonal | 10.6 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×768 [WXGA] 140PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 231.36(H)×138.816(V) mm |
| garis besar redup. | 250(H)×175(V) ×15.5(D) mm |
| daerah bezel | - |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 800 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 12/12 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | SWV, Normally Black, Transmissive |
| warna pendukung | 262K/16.7M 50% NTSC |
| sumber cahaya | WLED , 100K hours , With LED Driver |
| berat | 670g (Typ.) |
| dirancang untuk | Industrial Outdoor High Brightness |
| kecepatan bingkai | 60Hz |
| panel sentuh | PCAP |
| Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| LQ106K1LA01C | SHARP | 10.6 | 1280×768 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LQ106K1LA05 | SHARP | 10.6 | 1280×768 |
| LTD106EWNN | TOSHIBA | 10.6 | 1280×768 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTN106W1-L01 | Samsung | 10.6 | 1280×768 |
| LTN106W2-L01 | Samsung | 10.6 | 1280×768 |
