| Nomor Bagian | LQ106K1LA05 |
| Merek | SHARP |
| Ukuran | 10.6 |
| Aplikasi | NBPC |
| Resolusi | 1280×768 |
| Komposisi | LCM |
| Kecerahan | 280 |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | SHARP |
| model panel | LQ106K1LA05 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.6 inch |
| resolusi | 1280(RGB)×768 , WXGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 230.4×138.24 mm |
| garis besar | 257.8×152×5 mm |
| permukaan | Glare (Haze 0%), Hard coating (2H), Antireflection |
| kecerahan | 280 cd/m² (Typ.) |
| rasio kontras | 350:1 (Typ.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 35 (Typ.)(Tr+Td) |
| sudut pandang | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 9S5PWLEDWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 6-bit), 20 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | NBPC |
