| Nomor Bagian | WF39BTZASDNN0 |
| Merek | Winstar |
| Ukuran | 3.9 |
| Aplikasi | Industrial Stretched |
| Resolusi | 480×128 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | Parallel |
| merek panel | Winstar |
| model panel | WF39BTZASDNN0 |
| ukuran panel | 3.9" (1/2 cut of 4.3") |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 480×128(RGB), 128PPI |
| format piksel | RGB Horizontal Stripe |
| area tampilan | 95.04(W)×25.34(H) mm |
| bukaan bezel | 97.04(W)×27.34(H) mm |
| ukuran garis besar | 105.5(W)×37(H) ×3.25(D) mm |
| permukaan | Antiglare |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) (TM) |
| sudut pandang | 75/75/75/75 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | 6 o'clock |
| waktu merespon | - |
| menampilkan warna | 16.7M |
| jenis lampu | WLED , Without Driver |
| frekuensi | - |
| layar sentuh | Without |
| berat panel | - |
| aplikasi | Industrial Stretched Bar LCD |
| antarmuka sinyal | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
