| Nomor Bagian | WF39ATIASDNN0 |
| Merek | Winstar |
| Ukuran | 3.9 |
| Aplikasi | Industrial Stretched |
| Resolusi | 480×128 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | - |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | Winstar |
| ukuran panel | 3.9" (1/2 cut of 4.3") |
| resolusi | 480(RGB)×128, 128PPI |
| area tampilan | 95.04(W)×25.34(H) mm |
| ukuran garis besar | 105.5(W)×40.64(H) ×3.15(D) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10) |
| tampilan terbaik di | 12 o'clock |
| menampilkan warna | 16.7M |
| frekuensi | - |
| berat | - |
| model panel | WF39ATIASDNN0 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 98.04(W)×28.34(H) mm |
| permukaan | Antiglare |
| rasio kontras | - |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | - |
| jenis lampu | WLED , Without Driver |
| layar sentuh | Without |
| aplikasi | Industrial Stretched Bar LCD |
