| Nomor Bagian | WEO012832AS |
| Merek | Winstar |
| Ukuran | 2.2 |
| Aplikasi | Handheld & PDA I |
| Resolusi | 128×32 |
| Komposisi | OLED , PM-OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Blue) |
| Lampu latar | self |
| Antarmuka | 8-bit |
| pabrikan | Winstar |
| nama model | WEO012832AS |
| ukuran layar | 2.2 inch |
| tipe layar | OLED , PM-OLED |
| nomor piksel | 128×32 59PPI |
| pengaturan | Rectangle |
| area aktif (mm) | 55.018 × 13.098 (H×V) |
| garis besar (mm) | 62 × 24 × 2.35 (H×V×D) |
| area bezel (mm) | 57.02 × 15.1 (H×V) |
| perlakuan | - |
| sudut pandang | - |
| tanggapan | - |
| pemandangan bagus di | Symmetry |
| mode kerja | - |
| kedalaman warna | Mono(Blue) |
| lampu latar | self |
| massa | - |
| digunakan untuk | Handheld & PDA Instruments & Meters |
| tingkat penyegaran | - |
| layar sentuh | Without |
| daftar ic driver | Built-in COG SSD1305Z |
| jenis sinyal | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC |
| sumber tegangan | 3.0V (Typ.) |
