| Nomor Bagian | WEO006432AW |
| Merek | Winstar |
| Ukuran | 0.49 |
| Aplikasi | Wearable |
| Resolusi | 64×32 |
| Komposisi | PM-OLED , OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antarmuka | I²C |
| merek panel | Winstar |
| ukuran panel | 0.49" |
| resolusi | 64×32, 145PPI |
| area tampilan | 11.18(W)×5.58(H) mm |
| ukuran garis besar | 14.5(W)×11.6(H) ×1.46(D) mm |
| sudut pandang | - |
| tampilan terbaik di | Symmetry |
| menampilkan warna | Mono(White) |
| frekuensi | - |
| ic pengemudi | COG Built-in SSD1306BZ |
| berat panel | - |
| antarmuka sinyal | I²C , 14 pins FPC |
| tegangan masukan | 3.0/7.5V (Typ.)(VDD/VCC) |
| lingkungan | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 85 °C |
| model panel | WEO006432AW |
| tipe panel | PM-OLED , OLED |
| format piksel | Rectangle |
| bukaan bezel | 12.58(W)×6.58(H) mm |
| permukaan | - |
| mode tampilan | - |
| waktu merespon | - |
| jenis lampu | self |
| layar sentuh | Without |
| aplikasi | Wearable |
