| Nomor Bagian | WEO001602CL |
| Merek | Winstar |
| Ukuran | 2.3 |
| Aplikasi | Instruments & Me |
| Resolusi | 16×27 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | 2000:1 |
| Warna | Mono(Yellow) |
| Lampu latar | self |
| Antarmuka | 8-bit |
| merek panel | Winstar |
| model panel | WEO001602CL |
| ukuran panel | 2.3" |
| tipe panel | PM-OLED, OLED |
| format tampilan | 16 characters × 2 lines, 7PPI |
| format huruf | 5×8 dots |
| ukuran karakter | 2.97×5.57(W×H) mm |
| nada karakter | 3.55×5.95(W×H) mm |
| area tampilan | 56.22(W)×11.52(H) mm |
| bukaan bezel | 58.22(W)×13.52(H) mm |
| ukuran garis besar | 68.5(W)×17.5(H) ×2.25(D) mm |
| permukaan | - |
| kecerahan | - |
| rasio kontras | 2000:1 (Typ.) (TM) |
| sudut pandang | 88/88/88/88 |
| mode tampilan | - |
| tampilan terbaik di | Symmetry |
| waktu merespon | 0.01 (Typ.) |
| menampilkan warna | Mono(Yellow) |
| jenis lampu | self |
| frekuensi | - |
| layar sentuh | Without |
| ic pengemudi | COG Built-in SSD1311M1Z |
| berat panel | - |
| aplikasi | Instruments & Meters |
| antarmuka sinyal | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 33 pins FPC |
| tegangan masukan | 3.3/5.0V (Typ.)(VDD) |
| AL1602B | Other | 2.3 | 16×2 |
| AMC162A | Other | 2.3 | 16×2 |
| AMC162B | Other | 2.3 | 16×2 |
| DMC-16202NY-LY-BJE-BLN | Kyocera | 2.3 | 16×2 |
| LS023B3UY01 | SHARP | 2.3 | 360×400 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
