| Nomor Bagian | WEO001602BW |
| Merek | Winstar |
| Ukuran | 1.22 |
| Aplikasi | Instruments & Me |
| Resolusi | 16×213 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antarmuka | CPU/SPI |
| merek panel | Winstar |
| model panel | WEO001602BW |
| ukuran panel | 1.22" |
| tipe panel | PM-OLED, OLED |
| format tampilan | 16 characters × 2 lines, 13PPI |
| format huruf | 5×8 dots |
| ukuran karakter | 1.66×2.84(W×H) mm |
| nada karakter | 1.94×3.11(W×H) mm |
| area tampilan | 30.69(W)×5.94(H) mm |
| bukaan bezel | 36(W)×10(H) mm |
| ukuran garis besar | 53(W)×20(H) ×7.6(D) mm |
| permukaan | - |
| sudut pandang | - |
| mode tampilan | - |
| tampilan terbaik di | Symmetry |
| waktu merespon | - |
| menampilkan warna | Mono(White) |
| jenis lampu | self |
| frekuensi | - |
| layar sentuh | Without |
| ic pengemudi | COGBuilt-in WS0012 |
| berat panel | - |
| aplikasi | Instruments & Meters |
| antarmuka sinyal | CPU/SPI , 16 pins FPC |
| tegangan masukan | 5.0V (Typ.) |
