| Nomor Bagian | WEH002002BW |
| Merek | Winstar |
| Ukuran | 5.7 |
| Aplikasi | Instruments & Me |
| Resolusi | 20×23 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antarmuka | CPU/SPI |
| merek panel | Winstar |
| model panel | WEH002002BW |
| ukuran panel | 5.7" |
| tipe panel | PM-OLED, OLED |
| format tampilan | 20 characters × 2 lines, 3PPI |
| format huruf | 5×8 dots |
| ukuran karakter | 6×9.66(W×H) mm |
| nada karakter | 7.32×10.98(W×H) mm |
| area tampilan | 145.08(W)×20.64(H) mm |
| bukaan bezel | 149.0(W)×23.0(H) mm |
| ukuran garis besar | 180(W)×40(H) ×9.3(D) mm |
| permukaan | - |
| sudut pandang | - |
| mode tampilan | - |
| tampilan terbaik di | Symmetry |
| waktu merespon | - |
| menampilkan warna | Mono(White) |
| jenis lampu | self |
| frekuensi | - |
| layar sentuh | Without |
| ic pengemudi | COBBuilt-in WS0010 |
| berat panel | - |
| aplikasi | Instruments & Meters |
| antarmuka sinyal | CPU/SPI , 16 pins Pad |
| tegangan masukan | 5.0V (Typ.) |
