| Nomor Bagian | WEG010032BW |
| Merek | Winstar |
| Ukuran | 2.4 |
| Aplikasi | Instruments & Me |
| Resolusi | 100×32 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antarmuka | CPU/SPI |
| merek panel | Winstar |
| model panel | WEG010032BW |
| ukuran panel | 2.4" |
| tipe panel | PM-OLED, OLED |
| resolusi | 100×32, 43PPI |
| format piksel | Rectangle |
| area tampilan | 58.95(W)×19.15(H) mm |
| bukaan bezel | 77(W)×25.2(H) mm |
| ukuran garis besar | 98(W)×60(H) ×10(D) mm |
| permukaan | - |
| sudut pandang | - |
| mode tampilan | - |
| tampilan terbaik di | Symmetry |
| waktu merespon | - |
| menampilkan warna | Mono(White) |
| jenis lampu | self |
| frekuensi | - |
| layar sentuh | Without |
| ic pengemudi | COG Built-in WS0010 |
| berat panel | - |
| aplikasi | Instruments & Meters |
| antarmuka sinyal | CPU/SPI , 16 pins FPC |
| tegangan masukan | 5.0V (Typ.) |
