| Nomor Bagian | WEG010016DW |
| Merek | Winstar |
| Ukuran | 2.4 |
| Aplikasi | Instruments & Me |
| Resolusi | 100×16 |
| Komposisi | OLED, PM-OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antarmuka | CPU |
| pabrikan | Winstar |
| nama model | WEG010016DW |
| ukuran layar | 2.4 inch |
| tipe layar | OLED, PM-OLED |
| nomor piksel | 100×16 42PPI |
| pengaturan | Rectangle |
| area aktif (mm) | 59.95 × 11.15 (H×V) |
| garis besar (mm) | 85 × 30.5 × 10 (H×V×D) |
| area bezel (mm) | 66 × 16 (H×V) |
| perlakuan | - |
| sudut pandang | - |
| tanggapan | - |
| pemandangan bagus di | Symmetry |
| mode kerja | - |
| kedalaman warna | Mono(White) |
| lampu latar | self |
| massa | - |
| digunakan untuk | Instruments & Meters |
| tingkat penyegaran | - |
| layar sentuh | Without |
| daftar ic driver | Built-in COG WS0010 |
| jenis sinyal | CPU , Pad 14 pins |
| sumber tegangan | 5.0V (Typ.) |
| 24QVF2H | SII | 2.4 | 240×320 |
| A024CN02 VJ | AUO | 2.4 | 480×234 |
| AM-240320-024DT | Other | 2.4 | 240×320 |
| C0240QGLG-T | CMEL | 2.4 | 240×320 |
| COM24H2N62XLC | ORTUSTECH | 2.4 | 240×320 |
| LMS245DC08 | Samsung | 2.4 | 480×360 |
| LS024Q3UX12(G) | SHARP | 2.4 | 320×240 |
| PD024OX4 | E Ink | 2.4 | 480×234 |
| TD024THEB5 | TPO | 2.4 | 480×240 |
| UG-2864ASYPG01 | WiseChip | 2.4 | 128×64 |
