| Nomor Bagian | WB014ZNM-N00 |
| Merek | BOE |
| Ukuran | 1.39 |
| Aplikasi | Wearable Round Displ |
| Resolusi | 454×454 |
| Komposisi | AM-OLED , OLED |
| Kecerahan | |
| CR | 20000:1 |
| Warna | 16.7M |
| Lampu latar | self |
| Antarmuka | MIPI |
| merek panel | BOE |
| ukuran panel | 1.39" |
| resolusi | 454(RGB)×454, 325PPI |
| area tampilan | 35.412(W)×35.412(H) mm |
| ukuran garis besar | 38.212(W)×39.372(H) mm |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 103% NTSC |
| frekuensi | 60Hz |
| ic pengemudi | COG Built-in RM67162FI |
| berat panel | 2.64g |
| antarmuka sinyal | MIPI (1 data lane) , 20 pins Connector |
| tegangan masukan | 1.8/3.0/4.6/-2.4V (Typ.)(VDDIO/VCI/ELVDD/ELVSS) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
| model panel | WB014ZNM-N00 |
| tipe panel | AM-OLED , OLED |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | With Polarizer |
| rasio kontras | 20000:1 (Typ.) (TM) |
| mode tampilan | - |
| waktu merespon | 3 (Max.)(Tr+Td) |
| jenis lampu | self |
| layar sentuh | Without |
| aplikasi | Wearable Round Display |
