BOE VS035ZSM-NW0-69P0 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com

VS035ZSM-NW0-69P0


Merek
BOE
Ukuran
3.5
Aplikasi
HMD VR AR
Resolusi
1440×1600
Komposisi
LTPS TFT-LCD , LCM
Kecerahan
CR
700:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
In Stock
18448
Spesifikasi

Nomor Bagian VS035ZSM-NW0-69P0
MerekBOE
Ukuran3.5
AplikasiHMD VR AR
Resolusi1440×1600
KomposisiLTPS TFT-LCD , LCM
Kecerahan
CR700:1
Warna16.7M
Lampu latarWLED
Antarmuka
merekBOE
ukuran diagonal3.5 inch
format piksel1440(RGB)×1600  615PPI
daerah aktif59.4(H)×66(V) mm
daerah bezel-
pencahayaan200 cd/m² (Typ.)
arah pandanganSymmetry
sudut pandang70/70/70/70 (Typ.)(CR≥10)
warna pendukung16.7M   85% NTSC
berat17.0±2.0g
kecepatan bingkai90Hz
modelVS035ZSM-NW0-69P0
jenisLTPS TFT-LCD , LCM
konfigurasiRGB Vertical Stripe
garis besar redup.62.2(H)×73.6(V) mm
perlakuanWithout Polarizer, Hard coating (3H)
rasio kontras700:1 (Typ.) (TM)
waktu merespon5 (Max.)(G to G)
Modus operasiADS, Normally Black, Transmissive
sumber cahayaWLED  [5S2P] , W/O Driver
dirancang untukHMD VR AR
panel sentuhWithout
Model Keluarga
990000738A Innolux 3.5 320×240
LH350WS1-SD01 LG Display 3.5 640×960
LQ035Q5DG01 SHARP 3.5 320×240
LQ035Q7DB02R SHARP 3.5 240×320
LTP350QV-E06 Samsung 3.5 240×320
LTV350QV-F0E Samsung 3.5 320×240
NL2432HC22-22B NLT 3.5 240×320
TCG035QVLPDANN-GN50 Kyocera 3.5 320×240
TM035KDH03 Tianma 3.5 320×240
TM035KDH16-09 Tianma 3.5 320×240
