| Nomor Bagian | VLT270-SBL-FHD-168 |
| Merek | Vitrolight |
| Ukuran | 24.4 |
| Aplikasi | Digital Signage Stre |
| Resolusi | 1920×540 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | Vitrolight |
| model panel | VLT270-SBL-FHD-168 |
| ukuran panel | 24.4" (1/2 cut of 27.0") |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×540, 81PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 597.6(W)×168(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 630(W)×200(H) mm |
| permukaan | - |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 85/85/80/80 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | - |
| waktu merespon | 3.8 (Typ.)(G to G) |
| menampilkan warna | 16.7M 72% NTSC |
| jenis lampu | WLED |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | - |
| aplikasi | Digital Signage Stretched Bar LCD |
| antarmuka sinyal | LVDS (2 ch, 8-bit) Connector |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; - |
