Innolux V546HK3-LS5 Rev.C7 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


V546HK3-LS5 Rev.C7

V546HK3-LS5 Rev.C7
V546HK3-LS5 Rev.C7 thumb
Merek
Innolux
Ukuran
55
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
400
CR
5000:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
LVDS
In Stock
8580
Spesifikasi

Nomor Bagian V546HK3-LS5 Rev.C7
MerekInnolux
Ukuran55
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan400
CR5000:1
Warna16.7M
Lampu latarWLED
AntarmukaLVDS
merek panelCHIMEI INNOLUX
model panelV546HK3-LS5 Rev.C7
tipe panel a-Si TFT-LCD , LCM
ukuran panel55 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanSuper MVA, Normally Black, Transmissive
daerah aktif1209.6×680.4 mm
garis besar1237.4×711.3 mm
permukaanAntiglare (Haze 11%), Hard coating (3H)
kecerahan400 cd/m² (Typ.)
rasio kontras5000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon6 (Typ.)(G to G)
sudut pandang88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frekuensi120Hz (60Hz Input)
jenis lampuWLEDEmbedded (LED Driver)
antarmuka sinyalLVDS (2 ch, 8-bit), 61 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
