| Nomor Bagian | V500HJ1-PE8 Rev.C7 |
| Merek | Chimei Innolux |
| Ukuran | 50 |
| Aplikasi | Transparent Display |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 5000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | LVDS |
| merek | Chimei Innolux |
| model | V500HJ1-PE8 Rev.C7 |
| ukuran diagonal | 50 inch |
| jenis | a-Si TFT-LCD, CELL |
| format piksel | 1920(RGB)×1080 [FHD] 44PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 1095.84(H)×616.41(V) mm |
| garis besar redup. | 1116.38(H)×631.61(V) ×1.31(D) mm |
| daerah bezel | - |
| perlakuan | Antiglare (Haze 1%), Hard coating (3H) |
| pencahayaan | 0 cd/m² |
| rasio kontras | 5000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 8.5 (Typ.)(G to G) |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥20) |
| Modus operasi | Super MVA, Normally Black, Transmissive |
| ketebalan pelat | - |
| transmisi | 5.6% (Typ.)(with Polarizer) |
| warna pendukung | 16.7M 70% NTSC |
| sumber cahaya | No B/L |
| berat | 1.99±0.199Kgs |
| dirancang untuk | Transparent Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| detail d-ic | COF Built-in 6 source + 4 gate chips |
| tipe antarmuka | LVDS (2 ch, 8-bit) Connector |
| Sumber Daya listrik | 12.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
