V470H2-L01

V470H2-L01
V470H2-L01
V470H2-L01 thumb V470H2-L01 thumb
Merek
Innolux
Ukuran
47
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
500
CR
4000:1
Warna
16.7M
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
6781
Spesifikasi

Nomor Bagian V470H2-L01
MerekInnolux
Ukuran47
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan500
CR4000:1
Warna16.7M
Lampu latarCCFL
AntarmukaLVDS
merek panelCMO
model panelV470H2-L01
tipe panel a-Si TFT-LCD , LCM
ukuran panel47 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanSuper MVA, Normally Black, Transmissive
daerah aktif1039.68×584.82 mm
garis besar1096×640 mm
permukaanAntiglare (Haze 11%), Hard coating (3H)
kecerahan500 cd/m² (Typ.)
rasio kontras4000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon6.5 (Typ.)(G to G)
sudut pandang88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frekuensi60Hz
jenis lampu12 pcsCCFLEmbedded (Inverter)
antarmuka sinyalLVDS (2 ch, 8-bit), 51 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
LC470EUE-SEF1 LG Display 47 1920×1080
LC470EUF-FFP1 LG Display 47 1920×1080
LC470EUN-SEM2 LG Display 47 1920×1080
LC470EUN-SFF1 LG Display 47 1920×1080
LC470EUN-SFM1 LG Display 47 1920×1080
T470HVD01.1 AUO 47 1920×1080
V470H1-L03 Innolux 47 1920×1080
V470H1-L08 Innolux 47 1920×1080
V470H2-L01 Innolux 47 1920×1080
V470H2-LE1 Innolux 47 1920×1080
