V460H1-LS2 Rev.C7

V460H1-LS2 Rev.C7
V460H1-LS2 Rev.C7
V460H1-LS2 Rev.C7 thumb V460H1-LS2 Rev.C7 thumb
Merek
Innolux
Ukuran
46
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
370
CR
5000:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
LVDS
In Stock
19
Spesifikasi

Nomor Bagian V460H1-LS2 Rev.C7
MerekInnolux
Ukuran46
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan370
CR5000:1
Warna16.7M
Lampu latarWLED
AntarmukaLVDS
merek panelCHIMEI INNOLUX
model panelV460H1-LS2 Rev.C7
tipe panel a-Si TFT-LCD , LCM
ukuran panel46 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanSuper MVA, Normally Black, Transmissive
daerah aktif1018.08×572.67 mm
garis besar1056.9×612.3 mm
permukaanAntiglare (Haze 11%), Hard coating
kecerahan370 cd/m² (Typ.)
rasio kontras5000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon6 (Typ.)(G to G)
sudut pandang88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frekuensi120Hz (60Hz Input)
jenis lampuWLEDEmbedded (LED Driver)
antarmuka sinyalLVDS (4 ch, 10-bit), 61 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
LTY460HQ05-A01 Samsung 46 1920×1080
T460HW03 VB AUO 46 1920×1080
V460H1-L09 Innolux 46 1920×1080
V460H1-L12 Innolux 46 1920×1080
V460H1-LE3 Innolux 46 1920×1080
V460H1-LH9 Innolux 46 1920×1080
V460H1-LS1 Innolux 46 1920×1080
V460H1-LS1 Rev.C6 Innolux 46 1920×1080
V460H1-LS2 Innolux 46 1920×1080
V460H1-LS2 Rev.C7 Innolux 46 1920×1080
