| Nomor Bagian | V400HJ6-PE1 Rev.CA |
| Merek | Innolux |
| Ukuran | 40 |
| Aplikasi | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | CELL, a-Si TFT-LCD |
| Kecerahan | |
| CR | 5000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | LVDS |
| pabrikan | Innolux |
| nama model | V400HJ6-PE1 Rev.CA |
| ukuran layar | 40 inch |
| tipe layar | CELL, a-Si TFT-LCD |
| nomor piksel | 1920(RGB)×1080 (FHD) 55PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 878.112 × 485.352 (H×V) |
| garis besar (mm) | 888.392 × 494.152 × 1.29 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Antiglare (Haze 1%), Hard coating (3H) |
| pencahayaan | 0 cd/m² |
| rasio kontras | 5000 : 1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tanggapan | 8.5 (Typ.)(G to G) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | MVA, Normally Black, Transmissive |
| ketebalan kaca | 0.50+0.50 mm |
| keterusan | 5.5% (Typ.)(with Polarizer) |
| kedalaman warna | 16.7M 72% NTSC |
| lampu latar | No B/L |
| massa | 1.40±0.07Kgs |
| digunakan untuk | TV Sets |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| daftar ic driver | Built-in COF 8 source + 4 gate chips |
| jenis sinyal | LVDS (2 ch, 8-bit) , Connector 51 pins |
| sumber tegangan | 12.0V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
