Nomor Bagian | V390HJ1-LE6 |
Merek | Innolux |
Ukuran | 39 |
Aplikasi | LCTV |
Resolusi | 1920×1080 |
Komposisi | LCM |
Kecerahan | 350 |
CR | 3500:1 |
Warna | 16.7M |
Lampu latar | WLED |
Antarmuka | LVDS |
merek panel | CHIMEI INNOLUX |
model panel | V390HJ1-LE6 |
tipe panel | a-Si TFT-LCD , LCM |
ukuran panel | 39 inch |
resolusi | 1920(RGB)×1080 , FHD |
mode tampilan | Super MVA, Normally Black, Transmissive |
daerah aktif | 853.92×480.33 mm |
garis besar | 873.32×501.63 mm |
permukaan | Antiglare (Haze 1%), Hard coating (3H) |
kecerahan | 350 cd/m² (Typ.) |
rasio kontras | 3500:1 (Typ.) |
menampilkan warna | 16.7M (8-bit), CIE193168% |
waktu merespon | 8.5 (Typ.)(G to G) |
sudut pandang | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
frekuensi | 60Hz |
jenis lampu | WLEDEmbedded (LED Driver) |
antarmuka sinyal | LVDS (2 ch, 8-bit), 51 pins |
tegangan masukan | 12.0V (Typ.) |
aplikasi | LCTV |
