| Nomor Bagian | V236BJ1-LE2 Rev.CA |
| Merek | Innolux |
| Ukuran | 23.6 |
| Aplikasi | TV Sets |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | Innolux |
| model | V236BJ1-LE2 Rev.CA |
| ukuran diagonal | 23.6 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1366(RGB)×768 [WXGA] 66PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 521.471(H)×293.184(V) mm |
| garis besar redup. | - |
| pencahayaan | - |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 8.5 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| Modus operasi | AAS, Normally Black, Transmissive |
| warna pendukung | 16.7M 72% NTSC |
| sumber cahaya | WLED |
| berat | - |
| dirancang untuk | TV Sets |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Sumber Daya listrik | 12.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
