| Nomor Bagian | TX54D31VC0CAB |
| Merek | KOE |
| Ukuran | 21.3 |
| Aplikasi | Industrial |
| Resolusi | 1600×1200 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | 6 |
| Antarmuka | LVDS |
| pabrikan | KOE |
| nama model | TX54D31VC0CAB |
| ukuran layar | 21.3 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 1600(RGB)×1200 (UXGA) 94PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 432 × 324 (H×V) |
| garis besar (mm) | 460.6 × 362 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Antiglare |
| pencahayaan | 450 cd/m² (Typ.) |
| rasio kontras | 500 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 15/10 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M |
| lampu latar | 6 pcs CCFL |
| massa | 2.700/3.00Kgs (Typ./Max.) |
| digunakan untuk | Industrial |
| tingkat penyegaran | - |
| layar sentuh | Without |
| jenis sinyal | LVDS (2 ch, 8-bit) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| LTM213U4-L01 | Samsung | 21.3 | 1600×1200 |
| LTM213U6-L01 | Samsung | 21.3 | 1600×1200 |
| NL160120BC27-14 | NLT | 21.3 | 1600×1200 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07 | NLT | 21.3 | 1600×1200 |
| NL204153AC21-22 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-04A | NLT | 21.3 | 2048×1536 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
| R213T3-L02 | Innolux | 21.3 | 2560×2048 |
