| Nomor Bagian | TX20D202VM2BAA |
| Merek | HITACHI |
| Ukuran | 8.0 |
| Aplikasi | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | , |
| Antarmuka | LVDS |
| pabrikan | HITACHI |
| nama model | TX20D202VM2BAA |
| ukuran layar | 8.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 800(RGB)×480 (WVGA) 116PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 174 × 104.4 (H×V) |
| garis besar (mm) | - |
| area bezel (mm) | - |
| perlakuan | Antiglare |
| pencahayaan | - |
| rasio kontras | 600 : 1 (Typ.) (TM) |
| sudut pandang | - |
| tanggapan | - |
| pemandangan bagus di | - |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K |
| lampu latar | , No Driver |
| massa | - |
| digunakan untuk | Industrial |
| jenis sinyal | LVDS |
