| Nomor Bagian | TX18D211VM0BAA |
| Merek | KOE |
| Ukuran | 7.0 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 800×480 |
| Komposisi | LTPS TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | KOE |
| model panel | TX18D211VM0BAA |
| ukuran panel | 7.0" |
| tipe panel | LTPS TFT-LCD, LCM |
| resolusi | 800(RGB)×480, WVGA, 133PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 152.4(W)×91.44(H) mm |
| bukaan bezel | 156.2(W)×94.5(H) mm |
| ukuran garis besar | 167.7(W)×109.5(H) ×20.3(D) mm |
| permukaan | - |
| kecerahan | 1200 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | IPS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| menampilkan warna | 262K 73% NTSC |
| jenis lampu | WLED , 50K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 219g (Typ.) |
| aplikasi | Industrial Outdoor High Brightness Automotive Display |
| antarmuka sinyal | LVDS (1 ch, 6-bit) , 20 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
