| Nomor Bagian | TX17D01VM2EAB |
| Merek | KOE |
| Ukuran | 6.5 |
| Aplikasi | IA |
| Resolusi | 640×480 |
| Komposisi | LCM |
| Kecerahan | 1000 |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | HITACHI |
| model panel | TX17D01VM2EAB |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 6.5 inch |
| resolusi | 640(RGB)×480 , VGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 132.48×99.36 mm |
| garis besar | 153×118 mm |
| permukaan | Glare (Haze 0%), Antireflection |
| kecerahan | 1000 cd/m² (Typ.) |
| rasio kontras | 600:1 (Typ.) |
| menampilkan warna | 262K (6-bit), CIE193150% |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| sudut pandang | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 3S4PWLEDEmbedded (LED Driver) |
| antarmuka sinyal | CMOS (1 ch, 6-bit), 31 pins |
| tegangan masukan | 3.3V (Typ.)(VDD) |
| aplikasi | IA |
