| Nomor Bagian | TX11D201VM0BAA |
| Merek | KOE |
| Ukuran | 4.2 |
| Aplikasi | Automotive Display |
| Resolusi | 480×272 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | Parallel |
| merek | KOE |
| model | TX11D201VM0BAA |
| ukuran diagonal | 4.2 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 480(RGB)×272 [WQVGA] 131PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 92.88(H)×52.632(V) mm |
| garis besar redup. | 102.5(H)×69(V) ×15.5(D) mm |
| daerah bezel | 95.28(H)×55.07(V) mm |
| perlakuan | Antiglare, Hard coating (2H) |
| pencahayaan | 750 cd/m² (Typ.) |
| rasio kontras | 1500:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M 65% NTSC |
| sumber cahaya | WLED [6S1P] , 50K hours , With LED Driver |
| berat | 97.0g (Typ.) |
| dirancang untuk | Automotive Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | Parallel RGB (1 ch, 8-bit) , 68 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
