| Nomor Bagian | TV156FHM-NH1 |
| Merek | BOE |
| Ukuran | 15.6 |
| Aplikasi | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek | BOE |
| ukuran diagonal | 15.6 inch |
| format piksel | 1920(RGB)×1080 [FHD] 141PPI |
| daerah aktif | 344.16(H)×193.59(V) mm |
| daerah bezel | - |
| pencahayaan | 250 cd/m² (Typ.) |
| arah pandangan | Symmetry |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| warna pendukung | 262K 45% NTSC |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | TV156FHM-NH1 |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 350.76(H)×216.2(V) ×3.2(D) mm |
| perlakuan | Antiglare, Hard coating |
| rasio kontras | 800:1 (Typ.) (TM) |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| Modus operasi | IPS, Normally Black, Transmissive |
| sumber cahaya | WLED , With LED Driver |
| dirancang untuk | Laptop |
| panel sentuh | Without |
| B156XW04 V6 | AUO | 15.6 | 1366×768 |
| G156XW01 V1 | AUO | 15.6 | 1366×768 |
| LP156WH3-TLC1 | LG Display | 15.6 | 1366×768 |
| LQ156M3LW01 | SHARP | 15.6 | 1920×1080 |
| LTN156AT02-A11 | Samsung | 15.6 | 1366×768 |
| LTN156AT20-W01 | Samsung | 15.6 | 1366×768 |
| M156MWR1 R0 | IVO | 15.6 | 1366×768 |
| N156BGE-L62 | Innolux | 15.6 | 1366×768 |
| N156HGE-EA1 | Innolux | 15.6 | 1920×1080 |
| N156HGE-EA2 | Innolux | 15.6 | 1920×1080 |
