| Nomor Bagian | TV070WSM-TL1 |
| Merek | BOE |
| Ukuran | 7.0 |
| Aplikasi | Pad & Tablet |
| Resolusi | 600×1024 |
| Komposisi | Assembly , a-Si TF |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 6S3P |
| Antarmuka | MIPI |
| pabrikan | BOE |
| nama model | TV070WSM-TL1 |
| ukuran layar | 7.0 inch |
| tipe layar | Assembly , a-Si TFT-LCD |
| nomor piksel | 600(RGB)×1024 (WSVGA) 170PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 89.28 × 152.37 (H×V) |
| garis besar (mm) | 97 × 188.26 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Hard coating |
| pencahayaan | 300 cd/m² (Typ.) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | - |
| kedalaman warna | 16.7M 50% NTSC |
| lampu latar | 6S3P WLED , No Driver |
| massa | 125g (Max.) |
| digunakan untuk | Pad & Tablet |
| tingkat penyegaran | 60Hz |
| layar sentuh | On-Cell Touch |
| jenis sinyal | MIPI (4 data lanes) , 39 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| AT070TN92 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.1 TP | Innolux | 7.0 | 800×480 |
| CLAA070LF06CW | CPT | 7.0 | 800×480 |
| HJ070NA-13A | Innolux | 7.0 | 1024×600 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LB070W02-TMJ2 | LG Display | 7.0 | 480×234 |
| LQ070Y5DG11 | SHARP | 7.0 | 800×480 |
| P070ACB-DB1 | Innolux | 7.0 | 600×1024 |
| TPF0702002N | JDI | 7.0 | 1200×1920 |
