| Nomor Bagian | TV070WSM-NM0 |
| Merek | BOE |
| Ukuran | 7.0 |
| Aplikasi | Pad & Tablet |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | BOE |
| model panel | TV070WSM-NM0 |
| ukuran panel | 7.0" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1024(RGB)×600, WSVGA, 169PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 153.6(W)×90(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 161.16(W)×100.97(H) ×4.8(D) mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 450 cd/m² (Typ.) |
| rasio kontras | 900:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | ADS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| menampilkan warna | 16.7M 50% NTSC |
| jenis lampu | WLED , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 90.0g (Max.) |
| aplikasi | Pad & Tablet |
| antarmuka sinyal | MIPI (4 data lanes) , 40 pins Connector |
| tegangan masukan | 1.8/3.3/9/19/-7V (Typ.)(VDD1/VDD3/AVDD/VGH/VGL) |
| lingkungan | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 85 °C |
