| Nomor Bagian | TPM0501010P |
| Merek | JDI |
| Ukuran | 5.0 |
| Aplikasi | Mobile Phone |
| Resolusi | 1080×1920 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek | JDI |
| model | TPM0501010P |
| ukuran diagonal | 5.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1080(RGB)×1920 [FHD] 445PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 61.641(H)×109.584(V) mm |
| garis besar redup. | 64.04(H)×116.52(V) ×1.48(D) mm |
| pencahayaan | 450 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M 85% NTSC |
| sumber cahaya | WLED [7S2P] , W/O Driver |
| berat | TBD |
| dirancang untuk | Mobile Phone |
| kecepatan bingkai | 60Hz |
| panel sentuh | In-Cell Touch |
| tipe antarmuka | MIPI (4 data lanes) , 40 pins Connector |
| Sumber Daya listrik | 1.8/5.5/-5.5V (Typ.)(IOVCC/AVDD/AVEE) |
| lingkungan | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
