| Nomor Bagian | TM150TDSG80 |
| Merek | TIANMA |
| Ukuran | 15.0 |
| Aplikasi | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | TIANMA |
| model panel | TM150TDSG80 |
| ukuran panel | 15.0" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1024(RGB)×768, XGA, 85PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 304.128(W)×228.096(H) mm |
| bukaan bezel | 307.4(W)×231.3(H) mm |
| ukuran garis besar | 326.5(W)×253.5(H) ×10(D) mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | 12 o'clock |
| waktu merespon | 8 (Typ.)(Tr+Td) |
| menampilkan warna | 262K/16.7M 60% NTSC |
| jenis lampu | WLED , 30K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | TBD |
| aplikasi | Industrial |
| antarmuka sinyal | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -10 ~ 65 °C ; Storage Temp.: -20 ~ 65 °C |
