| Nomor Bagian | TM123XDHP90 |
| Merek | TIANMA |
| Ukuran | 12.3 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 10S4P |
| Antarmuka | LVDS |
| merek panel | TIANMA |
| model panel | TM123XDHP90 |
| ukuran panel | 12.3" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×720, 166PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 292.32(W)×109.62(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 311(W)×130(H) ×15.7(D) mm |
| permukaan | Antiglare (Haze 28%) |
| kecerahan | 1000 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | - |
| mode tampilan | SFT, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| menampilkan warna | 16.7M 98% sRGB |
| jenis lampu | 10S4P WLED , 10K hours , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 490g (Typ.) |
| aplikasi | Industrial Outdoor High Brightness Automotive Display |
| antarmuka sinyal | LVDS (2 ch, 8-bit) , 50 pins FPC |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
