| Nomor Bagian | TM123XDHP01 |
| Merek | TIANMA |
| Ukuran | 12.3 |
| Aplikasi | Industrial Automotiv |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek | TIANMA |
| ukuran diagonal | 12.3 inch |
| format piksel | 1920(RGB)×720 166PPI |
| daerah aktif | 292.32(H)×109.62(V) mm |
| pencahayaan | - |
| arah pandangan | Symmetry |
| sudut pandang | - |
| warna pendukung | 16.7M sRGB |
| berat | - |
| kecepatan bingkai | 60Hz |
| lingkungan | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
| model | TM123XDHP01 |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | - |
| rasio kontras | 1000:1 (Typ.) (TM) |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| Modus operasi | SFT, Normally Black, Transmissive |
| sumber cahaya | WLED |
| dirancang untuk | Industrial Automotive Display |
| panel sentuh | Without |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
