| Nomor Bagian | TM103XDHP95 |
| Merek | TIANMA |
| Ukuran | 10.3 |
| Aplikasi | Outdoor High Brightn |
| Resolusi | 1920×720 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 11S3P |
| Antarmuka | |
| pabrikan | TIANMA |
| nama model | TM103XDHP95 |
| ukuran layar | 10.3 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1920(RGB)×720 200PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 243.648 × 91.368 (H×V) |
| garis besar (mm) | 261 × 110.5 × 14.65 (H×V×D) |
| area bezel (mm) | 246.65 × 94.37 (H×V) |
| perlakuan | Antiglare |
| pencahayaan | 950 cd/m² (Typ.) |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10) |
| tanggapan | 35 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | SFT, Normally Black, Transmissive |
| kedalaman warna | 16.7M 99% sRGB |
| lampu latar | 11S3P WLED , 10K hours , No Driver |
| massa | TBD |
| digunakan untuk | Outdoor High Brightness Automotive Display |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
