| Nomor Bagian | TM097TDHG04-62 |
| Merek | TIANMA |
| Ukuran | 9.7 |
| Aplikasi | Pad & Tablet Industr |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | TIANMA |
| ukuran diagonal | 9.7 inch |
| format piksel | 1024(RGB)×768 [XGA] 132PPI |
| daerah aktif | 196.608(H)×147.456(V) mm |
| daerah bezel | 200.91(H)×152.27(V) mm |
| pencahayaan | 350 cd/m² (Typ.) |
| arah pandangan | 12 o'clock |
| sudut pandang | 70/70/60/70 (Typ.)(CR≥10) |
| warna pendukung | 262K 50% NTSC |
| berat | 200g (Typ.) |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | LVDS (1 ch, 6-bit) , 30 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | TM097TDHG04-62 |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 210.2(H)×166.3(V) ×6.5(D) mm |
| perlakuan | Clear |
| rasio kontras | 500:1 (Typ.) (TM) |
| waktu merespon | 20/25 (Typ./Max.)(Tr+Td) |
| Modus operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED [6S6P] , 30K hours , W/O Driver |
| dirancang untuk | Pad & Tablet Industrial |
| panel sentuh | Without |
