| Nomor Bagian | TM070RDHG34 |
| Merek | TIANMA |
| Ukuran | 7.0 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 800×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 3S8P |
| Antarmuka | |
| pabrikan | TIANMA |
| nama model | TM070RDHG34 |
| ukuran layar | 7.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 800(RGB)×480 (WVGA) 134PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 154.08 × 85.92 (H×V) |
| garis besar (mm) | 164.9 × 100 × 6 (H×V×D) |
| area bezel (mm) | 157.08 × 89.39 (H×V) |
| perlakuan | Antiglare |
| pencahayaan | 1000 cd/m² (Typ.) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| sudut pandang | 70/70/60/70 (Typ.)(CR≥10) |
| tanggapan | 25 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | 6 o'clock |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 16.7M 50% NTSC |
| lampu latar | 3S8P WLED , 50K hours , No Driver |
| massa | TBD |
| digunakan untuk | Industrial Outdoor High Brightness Automotive Display |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
