| Nomor Bagian | TM070RDHG25 |
| Merek | TIANMA |
| Ukuran | 7.0 |
| Aplikasi | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | 3S8P |
| Antarmuka | |
| merek panel | TIANMA |
| ukuran panel | 7.0" |
| resolusi | 800(RGB)×480, WVGA, 134PPI |
| area tampilan | 154.08(W)×85.92(H) mm |
| ukuran garis besar | 164.9(W)×100(H) ×8.1(D) mm |
| kecerahan | 450 cd/m² (Typ.) |
| sudut pandang | 80/80/60/80 (Typ.)(CR≥10) |
| tampilan terbaik di | 6 o'clock |
| menampilkan warna | 262K 50% NTSC |
| frekuensi | 60Hz |
| berat | TBD |
| model panel | TM070RDHG25 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 157.08(W)×89.39(H) mm |
| permukaan | Antiglare |
| rasio kontras | 1000:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 15 (Typ.)(Tr+Td) |
| jenis lampu | 3S8P WLED , 20K hours , Without Driver |
| layar sentuh | Without |
| aplikasi | Industrial |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
