| Nomor Bagian | TM070RDHG12 |
| Merek | TIANMA |
| Ukuran | 7.0 |
| Aplikasi | Portable DVD Player |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | Parallel |
| merek | TIANMA |
| model | TM070RDHG12 |
| ukuran diagonal | 7.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 134PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 154.08(H)×85.92(V) mm |
| garis besar redup. | 164.9(H)×100(V) ×6(D) mm |
| daerah bezel | 157.08(H)×89.39(V) mm |
| perlakuan | Antiglare |
| pencahayaan | 350 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) (TM) |
| arah pandangan | 12 o'clock |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| sudut pandang | 70/70/60/70 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 262K/16.7M 50% NTSC |
| sumber cahaya | WLED [3S7P] , 20K hours , W/O Driver |
| berat | 165g (Typ.) |
| dirancang untuk | Portable DVD Player Digital Photo Frame |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | Parallel RGB (1 ch, 6/8-bit) , 60 pins FPC |
| Sumber Daya listrik | 3.3/10.6/10.6/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
