| Nomor Bagian | TM057KDH01-41 |
| Merek | TIANMA |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | 5S3P |
| Antarmuka | Parallel |
| merek panel | TIANMA |
| model panel | TM057KDH01-41 |
| ukuran panel | 5.7" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 320(RGB)×240, QVGA, 70PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 115.2(W)×86.4(H) mm |
| bukaan bezel | 118.2(W)×89.4(H) mm |
| ukuran garis besar | 144(W)×104.6(H) ×12.8(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) (TM) |
| sudut pandang | 70/70/70/60 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | 12 o'clock |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| menampilkan warna | 262K 50% NTSC |
| jenis lampu | 5S3P WLED , 50K hours , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 160g (Typ.) |
| aplikasi | Industrial |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
